Precision Beam Control with 3224 Series SMD LEDs
Engineered for Precision. Designed for Density.

Our 3224 series SMD LEDs offer an ultra-narrow 20° viewing angle, delivering precise, high-intensity beams ideal for directional lighting in space-limited applications.

This focused output minimizes optical cross-talk, enabling high-density layouts without interference—perfect for compact circuit boards and tightly integrated systems and supports fully automated production while offering greater design freedom.

With precision optics and stable performance, the 3224 series is an optimal solution for:

Outdoor signaling: such as industrial indicator lights, control panel status LEDs, and power indicators in dense PCB layouts.

Traffic and guidance systems:including lane markers, signal modules, and road-side alerts—enhancing visibility and recognition over distance.

High-density LED displays: such as fine-pitch modules, benefit from focused light output that keeps each pixel sharp and distinct—delivering clearer text and graphics without unwanted light spill.

In optical design applications, the 3224 series helps reduce sensing interference by keeping light within a defined zone, enhancing both efficiency and accuracy. Ideal uses include:

Optical and sensor modules: barcode scanners, alignment systems, compact detection units, and machine vision lighting.

Wearable and medical devices: for use in biosensing, optical diagnostics, or as status indicators in miniaturized equipment.
